Operating Environment
10℃ – 40℃; Indoor; 10%-85%RH
Depth Technology
Structured Light
Depth Range
*0.6-8m
Wavelength
850nm
Processor
Orbbec ASIC
IMU
N/A
SDK
Orbbec OpenNI SDK
Spatial Precision
±3mm @ 1m
Depth FoV
58.4°H x 45.5°V
Depth Resolution and Frame Rate
640X480@30fps
RGB FoV
H66.1° V40.2°
RGB Resolution and Frame Rate
1920X1080@30fps
Power Consumption
Average <2.4W
Connector
USB 2.0 Type-A
Weight
310 ± 5g
Dimensions (W*H*D)
165mm x 48mm x 40mm
Installation
Bottom
10℃ – 40℃; Indoor; 10%-85%RH
Depth Technology
Structured Light
Depth Range
*0.6-8m
Wavelength
850nm
Processor
Orbbec ASIC
IMU
N/A
SDK
Orbbec OpenNI SDK
Spatial Precision
±3mm @ 1m
Depth FoV
58.4°H x 45.5°V
Depth Resolution and Frame Rate
640X480@30fps
RGB FoV
H66.1° V40.2°
RGB Resolution and Frame Rate
1920X1080@30fps
Power Consumption
Average <2.4W
Connector
USB 2.0 Type-A
Weight
310 ± 5g
Dimensions (W*H*D)
165mm x 48mm x 40mm
Installation
Bottom
