RealSense™ Depth Camera D555 introduces Power over Ethernet (PoE) interface on chip, expanding our portfolio of USB and GMSL/FAKRA products.
| Use Environment | Indoor/Outdoor |
| SoC | RealSense™ SoC V5 |
| Operating Case Temperature | -20oC to 50oC |
| Image Sensor Technology | Global Shutter |
| Depth Field of view (FOV) (H x V) | 87° × 58° |
| Depth Resolution | Up to 1280 × 720 |
| Depth Frame rate | Up to 90 FPS |
| Minimum Depth Distance (Min-Z) | 26cm (VGA) |
| RGB Resolution & Frame rate | Up to 1280 × 800. Up to 60 FPS |
| RGB Field of View (FOV), H x V | 90° × 65° |
| PoE Connector | RJ45 |
| USB Connector | USB-C (Can be used for power) |
| External HW Sync | Via the USB connector |
| IP Grade | IP65 |
| Power (Typical) | 5.5W |
| Dimensions | 167 x 42 x 48 mm |
