See Farther | See Clearer | See Sharper
Ready for Industrial Robots
Gemini 435Le is an industrial-grade stereo vision camera specifically engineered to tackle robotic vision challenges. Optimized for long-range missions, it is capable of performing diverse perception purposes while delivering exceptional depth data — empowering bulky robots to achieve stable, precise, and flexible positioning, navigation, and object recognition in harsh environments.
Push Depth Beyond Limits
Elevating Robotic Vision
Gemini 435Le delivers superior environmental adaptability and depth measurement performance. It provides low-noise, high-density environmental depth data to enhance path planning efficiency for robotic navigation. At the same time, it effortlessly overcomes measurement challenges in complex scenarios such as logistics, accurately reconstructing object contours across various materials to fully meet the requirements of high-precision recognition and measurement.
What’s Included:
Operating Environment
Indoor & Outdoor
Depth Technology
Active & Passive Stereo
Depth Range
0.31m – 20m+
Ideal Range
0.31m – 10m
IMU
Support
SDK
Orbbec SDK
Baseline
95mm
Spatial Precision
≤0.4% @ 2m; ≤0.8% @ 4m
Depth FoV
90° × 65° ± 3° @ 2m
Depth Resolution and Frame Rate
Up to： 1280 x 800 @ 10fps; 640 x 400 @ 20fps
Depth Shutter Type
Global Shutter
RGB FoV
94° × 68° ± 3°
RGB Resolution and Frame Rate
Up to： 1280 × 800 @ 10fps; 1280 x 720 @ 20fps
RGB Image Format
MJPEG & I420
RGB Shutter Type
Global Shutter
Power supply
Power supply by DC via M12 A-coded 9-24V ≥2A; Power supply by PoE via M12 A-coded IEEE 802.3af
Power Consumption
DC Average ≤ 6.5W (Peak ≤ 11W); PoE Average ≤ 8.0W (Peak ≤ 15W)
Protection
IP67
Multi-camera Hardware Sync
M12 A-coded
Operating Temperature
-10℃ – 50℃
Weight
520g ± 3g
Dimensions (W*H*D)
138.5 mm × 40.5 mm × 70.0 mm
Interface
M12, 8-pin, X-coded M12, 8-pin, A-coded
Installation
Back：4x M4; Bottom：4x M4; Top：4x M4
